Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12
A - 114
ser_flow RS-232 Flow Control
Description
This parameter sets the type of flow control that will be used on the RS-232
port. Hardware flow control is recommended for baud rates over 9600 bps.
Examples
System Parameters
dev_bootloader_ver Bootloader Version
Description
This parameter returns the bootloader version.
Argument Argument value
Channel Type Device-Specific System
Value Type List
Read/Write Mode Read/Write
Values none : No flow control (default)
hw : Hardware flow control (RTS/CTS)
Command Response Description
set ser_flow 1 hw val ser_flow 1 hw Sets the serial port flow control on device 1 (the first
device) to 'hw'.
set ser_flow 1 none val ser_flow 1 none Disables the serial port flow control on device 1 (the first
device) by setting the flow control to 'none'.
Argument Argument value
Channel Type Device-Specific System
Value Type String
Read/Write Mode Read-Only
System Limits Max String Length: 24
- Design Guide 1
- C16, C12, C8, and SR12 1
