Installing SoundStructure Devices
7 - 29
Removing Presets
Presets may be removed from the system by left clicking on the preset and then
clicking Remove Preset.
If the power-on preset is removed and the system rebooted, the system will
boot into the current settings if they have been stored in the configuration file.
Full preset execution does not generate any command acknowledgements from the
SoundStructure system. If specific parameters are required after a preset has been
executed, the values for the parameters should be queried after a preset has
executed.
The outputs of the system are muted during the execution of a full preset. The
outputs are unmuted after the preset has executed. This muting does not affect the
state of the safety mute or any other mute parameter.
