11 - 1
11
Specifications
Technical Specifications
Dimensions
• 19" (483 mm) W x 13.5" (343 mm) L x 1.75" (45 mm) H (one rack unit)
Weight
• 12 lbs. (5.5 kg) dry, 14 lbs. (6.4 kg) shipping
Connectors
• RS-232: DB9F
• OBAM In/Out: IEEE 1394B
• CLINK2: RJ45
• LAN: RJ45
• Control/Status: DB25F
• Audio: Mini (3.5 mm) quick connect terminal blocks
• IR Receive: Mini (3.5 mm) quick connect terminal block
Power
• Internal power supply
• Input voltage of 90-250 VAC; 50-60 Hz
• Line power requirements (including 0.6 PF): 130 VA (C16), 115 VA (C12),
105 VA (SR12), 95 VA (C8)
