Design Guide for the Polycom SoundStructure C16, C12, C8, and SR12
A - 38
Description
This parameter selects whether the gated (1) or ungated (0) version of the input
signal is sent to the output.
Examples
matrix_gate_type Select Gating Type
Row Phys Chans Conferencing Mic/Line Input, Sound Reinforcement Mic/Line
Input
Row Virt Chans Mono, Stereo
Col Phys Chans Conferencing Line Output, Sound Reinforcement Line
Output, Analog Telephony Output, Submix, ConferenceLink
Aux Output
Col Virt Chans Mono, Stereo
Default 0
Argument Argument value
Command Response Description
set matrix_gate "Table
Mic 1" "Phone Out" 1
val matrix_gate "Table
Mic 1" "Phone Out" 1
Tells the matrix to use the automixed version of the input
signal "Table Mic 1" when creating the output signal
"Phone Out".
set matrix_gate "Table
Mic 1" "Phone Out" 0
val matrix_gate "Table
Mic 1" "Phone Out" 0
Tells the matrix to use the un-automixed version of input
"Table Mic 1" when creating the output signal "Phone
Out".
Argument Argument value
Channel Type Matrix
Value Type List
Read/Write Mode Read/Write
Row Phys Chans Conferencing Mic/Line Input
Row Virt Chans Mono, Stereo
Col Phys Chans Conferencing Line Output, Sound Reinforcement Line
Output, Analog Telephony Output, Submix, ConferenceLink
Aux Output
Col Virt Chans Mono, Stereo
Values conf : Conference Style Gating (default)
sr : Sound Reinforcement Style Gating
